Product Details
＋- Binocular head
- HWF 10x/22mm eyepieces
- 6.7 to 45x Magnification
- 3W LED incident and transmitted illumination
The NexiusZoom ESD safe microscopes are perfect for analyzing all kinds of material surfaces or to observe larger objects in the electronic industry.
The body and stand are coated with a static dissipative paint eliminating harmful electrostatic discharges.
Microscope Specifications
| Viewing Head | Binocular head with 45° inclined tubes. Diopter adjustment ± 5° on two tubes. Interpupillary distance adjustable between 54 and 75 mm |
| Eyepieces | Pair wide field eyepieces HWF10x/22mm without eyecups |
| Objectives | 0.67x to 4.5x zoom objective, magnification from 6.7x to 45x. Field of view from 33 mm to 4.9 mm. Working distance 110 mm |
| Stand | Ergonomically pillar stand. Maximum object height 148 mm |
| Stage | Supplied with opaque stage plate, white/black stage plate and 2 object clamps |
| Illumination | Incident and transmitted 3W LED illumination with internal power supply. Both illumination intensities can be adjusted separately |
| Supplied with | Supplied with dust cover in Styrofoam case |
